Dimensions
Width 0.800 meter
Length 2.230 meter
Height 1.22 meter
Internal Diameter 0,78 meter
Internal Length 2.0 meter
Internal Volume 69.3 cu. Ft. / 1.962 cu. meter
Weight 543 Kg
Pressures
Maximum Operating Pressure 1 ATA / 2ATA ( testing Pressure 3 ATA)
Read more
Design Temperature 18 C to 38 C
Oxygen Supply Pressure 1 ATA / 2ATA (depending on the working pressure)
Oxygen Supply (Peak) Flow 5 L -10 L min
Ventilation Rate 90L/Min -150L/min
Pressure Change Rate
Emergency Depressurization Rate 2ATA to 1ATA in 120 sec
All Oxygen for Life systems meet or exceed current requirements of ASME, PVHO-1, and 13482 ISO and is CE mark for wellness device, is in the process for homologations under EU norm for “medical device”
Design Standards
– EN 13445 – – SR EN 13445/4;5-2014 – – ISO 14971/2012 – EN14931 (PVHO) — SR EN ISO 3452-1/2013 – SR EN ISO 23277/2015 – – SR EN ISO 17637/2011
